Model Number XJ-H1600 | |||
Brightness (lumens) | 3500 lumens | ||
Contrast ratio | Telephoto Mode | TBD | |
Zoom | 1.2X manual | ||
Focus | Manual Focus | ||
lens offset | 100% | ||
Light Source | Casio Laser & LED Hybrid | ||
Estimated Operating Life | up to 20,000 hours (warranty 3 years or 6,000 hours) | ||
Projection screen size | 27 to 300-inch diagonal | ||
Projection range | 60-inch screen | 6.3 ~ 7.6 ft | |
100-inch screen | 10.9 ~ 12.9 ft | ||
Minimum | 2.8 ft (27” diagonal) | ||
Projection ratio | 1.6 ~ 1.91:1 | ||
Projection system | DLP® | ||
Device Type | 0.7-inch DLP® chip | ||
Native Resolution | XGA 1024 x 768 | ||
Native Aspect Ratio | 4:3 | ||
Color reproduction | Full color (16.77 million colors) | ||
Keystone correction | Vertical +30° (Auto) Vertical + or - 30° (Manual) | ||
Dimensions | Including Projections Excluding Projections |
15.75 x 12.72 x 4.17 inches 15.75 x 12.72 x 3.78 inches |
|
Weight | 15.6 lbs | ||
Power Source | AC100~240V, 50/60Hz | ||
Power Consumption | Operating | TBD | |
Standby | TBD | ||
Security compatibility | Kensington compatible | Yes | |
Power ON password | Yes | ||
Ceiling mount | Yes | Compatible with Universal Projector Mount Solutions from 3rd party vendors | |
Mounting Screw size | M4/4 (Optional and sold Separately or included with mount) | ||
Manufactured in | China |
OTHER INFORMATION | |||
Usage Environment | Operating Temperature | 41~95°F | |
Operating Humidity | 20~80% (non condensation) | ||
High Altitude Mode | Yes (for operation 3,300~6,600 ft | ||
Remote Control Range | 16.5 ft Maximum | ||
Limited Warranty | 3 years Parts and Labor plus 3 years or 6,000 hours light source, see Warranty Statement included with product for complete details. | ||
Included Accessories | Wireless remote control, 6’ RGB cable, 6’ AV cable, 6’ AC Power Cord, Carry Bag, Manual on CD-ROM and booklet | ||
Optional Accessories | Active Shutter 3D Glasses (YA-G30)/ 2D-3D Conversion Software (YA-D30) | ||
Packing Information | Carton Dimensions | TBD | |
Carton Weight | TBD |
I/O CONNECTIVITY | |||
RGB/Component Video Input | mini D-Sub 15 pin x 2 Also use as YCbCr/YPbPr input - commercially available adapter required |
||
Native Resolution | XGA (1024 x 768) 786,432 pixels | ||
Digital Input | HDMI Type A x 1 (Locking Type) | ||
RGB Output | Mini D sub 15 pin x 1 | ||
Audio | Input | RCA (R/L) x1, Stereo mini x 2 | |
Output | Stereo Mini x 1 | ||
Speaker | 10W Monaural Speaker | ||
Video Signal Compatability | Video Systems | NTSC/ PAL/ PAL-N/ PAL-M/ PAL60/ SECAM | |
DTV/HDTV | 480i/480P/576i/576P/720P/1080i/1080p | ||
Video Input | Composite Video (RCA) x 1, S-Video x 1 | ||
Control Terminal | RS-232C (Mini D sub 9 pin) x 1 |
The Casio Pro Model Projectors have increased I/O connectivity, are DLP 3D Ready and have auto brightness adjustment to save power and reduce eye fatigue.
They are Interactive Whiteboard Ready (USB models only.) By using the optional Interactive Pen with any white surface, whether whiteboard, screen or wall. Use the Interactive Pen as a PC mouse to scroll and click through software applications or as a pen to draw, write and annotate images. They also include RJ-45 wired LAN, wireless presentations and MobiShow, WLAN presentations from smart phones and mobile devices and presentations from your thumb drive.
![]() ![]() ![]() ![]() ![]() ![]() ![]() |
Learn more about Casio's Pro Series Projectors | |
CASIO HYBRID LIGHT SOURCE By combining a laser, a fluorescent element and LED's Casio has created an original mercury-free hybrid light source capable of generating high brightness. Red is emitted by a high-lumen red LED. Blue is emitted by a high lumen blue LED. Green is achieved by converting blue laser light using a phosphor element. *The Casio Hybrid Light Source can only be replaced by the Casio Factory Service Center. Disassembly of the projector and/or use of its technology or components for other purposes is potentially dangerous and strictly prohibited. |
|
MERCURY FREE LIGHT SOURCE![]() |
|
Provides 10X longer light source life than Casio mercury lamp while being more economical based on lamp replacement. The Casio Hybrid Light Source projector features quick startup and shutdown. The projector reaches its maximum brightness in a minimum of 8 seconds and requires no cooling down period. | |
SUPERIOR COLOR, HIGH BRIGHTNESS![]() |
|
![]() |
|
Compared with conventional high-brightness projectors employing mercury lamps, Casio Hybrid Light Source technology cuts costs as well as the time and effort involved in lamp exchange while maintaining clear, high-quality images over an extended period. The LampFree® design is backed by a comprehensive 3 year warranty including the light source; users can expect reliable worry free operation from the Casio Hybrid Projectors. |
